DXMC20, DORIX Modular Euro Cylinder
Adjustable Length, Anti-Tamper Design, EN1303, TS007 1 Star
Product Overview
The Dorix DXMC20 is a flexible, modular euro cylinder engineered for custom-fit installations and advanced mechanical security. With adjustable sizing in 5mm increments and a reinforced bridge system, it suits a wide range of residential and commercial applications while reducing inventory needs.
- Availability: Available on request
- Shipping & Return information: Free delivery across the UK. 30-day return policy.
£45.00 (Inc. VAT)
- Key Features
- Compatibility
- Description
- Technical Details
- Resources
- FAQs
- Reviews (0)
- Modular adjustable length
- Customisable for single or double cylinder configurations
- Triple side pin layout for superior key security
- Sawable bridge to optimise stock and adapt to door variations
- Precision brass body with nickel finish
- Supplied with 3 dimple brass keys (nickel plated)
- Compatible with UPVC, timber, composite, and aluminium doors
- Cylinder lengths: Adjustable from 65mm to 110mm
- Cut-to-fit steel bar types: 32.5+32.5mm and 57.5+57.5mm in 5mm increments
- Modular Kit with full sizing matrix to guide assembly
Description
The Dorix DXMC20 is the go-to modular cylinder for locksmiths, housing developers, and security professionals who need installation flexibility without compromise. The smart, sawable bridge and sliding sleeve mechanism let you tailor the cylinder to the exact door thickness on-site.
This modular cylinder is also built to last, crafted from high-grade brass and finished in corrosion-resistant satin nickel. Its triple side pin system dramatically improves resistance to lock manipulation, making it ideal for high-turnover settings, retrofits, or projects with varied door requirements.
Each cylinder comes with three nickel-coloured dimple keys and fits all standard euro-profile lock cases. A full modular matrix is available to assist in selecting the required extension segments.
Accessories
- 3 Keys
- A full modular matrix
Warranty & & Support
- 1-year warranty
- UK-based support
- Type: Modular Euro Profile Cylinder
- Material: Brass body and mechanism
- Finish: Satin Nickel
- Keys: 3 nickel-plated dimple brass keys
- Configuration: Interchangeable single or double
- Length Range:
- Min: 65mm
- Max: 110mm
- Adjustable in 5mm steps
- Pins: 12-pin configuration
- Keyway: Dimple key
- Security Protections:
- Anti-Drill
- Anti-Pick
- Anti-Bump
- Anti-Snap
- Anti-Pull
- Application: Residential, commercial, and retrofit
- Compatibility: Euro-profile locks only
- Technical Datasheet
- Installation and Setup Manual
- Installation video
1- What does modular mean in this lock?
It allows for on-site customisation of cylinder length using 5mm extensions.
2- Can I convert between a single and double cylinder?
Yes. The DXMC20 supports both configurations with minimal effort.
3- How do I know which parts I need?
A complete matrix guide is available upon request. It shows all assembly combinations.
4- Is the modular kit included?
The core unit is supplied complete. Modular extension kits are available separately.
5- What security standards does it meet?
CE, UKCA, BSI 1-Star, and EN 1303 compliant.
6- Does it include keys?
Yes – 3 nickel-plated dimple keys are included.
7- What’s the material of the cylinder?
High-quality brass for durability and performance.
8- Is this suitable for external doors?
Absolutely. It offers strong protection for both interior and exterior applications.
9- What kind of keyway does it use?
Dimple keyway with 12-pin core.
10- Can it be installed in any Euro-profile lock case?
Yes, it’s designed to fit standard Euro mortices.
