The Skipton, DORIX Smart Cylinder Collection
UK Engineered
Mobile Access, RFID, NFC
Smart Home Integration, Wireless Online (via Gateway), Waterproof, Premium Body
Product Overview
The DORIX Smart Cylinder is inspired by Skipton Castle’s three-year stand against siege during the Civil War. Despite isolation and relentless attacks, its walls never yielded until peace terms were negotiated. This endurance made Skipton a lasting symbol of resilience and adaptability in times of uncertainty.
The Skipton collection is designed with the same philosophy of legendary strength, combining smart convenience with proven security. It offers secure, keyless control across a wide range of applications. Whether it’s a front door, flat, rental property, office, cabinet, or outbuilding, Skipton adapts to the cylinder you already have with five types: Thumbturn, Screw-in, Rim, Cam, and Scandinavian (oval).
- Key Features
- Compatibility
- Installation and Support
- Technical Specifications
- Resources
- 3 Unlocking Methods: RFID card, NFC, and DORIX App
- Wireless Online: Via an optional DORIX BLE‑to‑Wi‑Fi gateway (DXAC20)
- App Control: Remote unlock, user management, alerts, and log history.
- Smart Home Integration: Works with the DORIX App, Smart Life, and Tuya Smart platforms
- Outdoor-ready: IP68 protection, Corrosion resistance and −25 °C to +65 °C operating range
- High Security: Free-rotating outer knob, anti-drill, mechanical attack resistance, high‑frequency resonance resistance
- Quiet operation: Smooth electronic clutch with low‑noise drive
- Flexible sizes: Base 32.5/32.5 mm Euro core, extendable up to 62.5mm on one side
- Low running cost: 2 × CR2 lithium with up to 25,000 cycles (typically 2 years)
- Simple Installation: Fits in as little as 10 minutes
- Smoke Resistance: Suitable for use on smoke door assemblies
Description
| Cylinder Types |
| Installation & Maintenance |
- Fit time: Approx. 10 minutes
- Tools required: Screwdriver, Proprietary opening tool (supplied)
- Do NOT use oil or WD-40 lubricants
- Only DORIX Graphite Powder Lubricant (DXAC50) must be used.
- Replace batteries every 24 months (based on usage) or as needed
- Clean gently with a dry cloth
| Warranty & Support |
- 2-year standard warranty (Free activation required via dorix.com)
- UK-based customer service
| What’s Included |
- The Skipton, DORIX Smart Cylinder
- Proprietary opening tool
- 3 × Mifare RFID cards
- 2 × CR2 lithium batteries
- Installation screw(s)
- The Skipton user manual
- DORIX Warranty Card
| Model Code: | DXSC10 |
| Trademark: | Skipton |
| Material: | Stainless Steel, Anodised Aluminium, Brass cylinder |
| Finish: | Matt nickel-plated |
| Unlocking Options: | RFID Card, NFC, DORIX App |
| Cylinder Types: | Thumbturn / Screw-in / Rim / Cam / Scandinavian (Oval) |
| Sizes: | 32.5/32.5 mm Euro core, extends up to 62.5mm on one side with 5mm and 10mm extension parts |
| Handing: | Non-handed |
| User Capacity: | Up to 100 |
| RFID Card Capacity: | Up to 100 |
| RFID Card Type: | Mifare Classic 1K |
| Reading Range: | < 20mm |
| Power Supply: | 2 × CR2 lithium |
| Battery Life: | 24 months |
| Low Battery Alarm: | Yes |
| Working Temperature: | -25°C to +65°C |
| Waterproof: | IP68, completely dust-tight and waterproof |
| Door Thickness: | 35-125mm |
| Connectivity: | Bluetooth (Wireless Online via an optional BLE‑to‑Wi‑Fi gateway) |
| App Control: | Remote control, user management, alerts, log history, and OTA firmware updates |
| Smart Home Integration: | Via DORIX App, Smart Life App, or Tuya Smart App |
| Cycle Testing: | Over 1,000,000 operational cycles |
| Security Features: | Free‑rotating outer knob, anti-drill construction, mechanical attack resistance, high‑frequency resonance resistance |
| External Power:
|
Electronic protection against reversed polarity or surges |
| Outer Knob Width: | 54mm |
| Outer Knob Height: | 44mm |
| Recommended Use: | Front door, flat, rental property, office, cabinet |
| Certification & Compliance: |
CE, UKCA, FCC, RoHS, ISO 9001 SKG 3 Star BS EN 15684-2020: 1-6-A-4-3-D-3-B |
| GTINs: | 5061099880046 (DXSC10)
5061099880053 (DXSC20) 5061099880060 (DXSC30) 5061099880077 (DXSC40) 5061099880084 (DXSC50) |
